Technical information:

• Grizzly grid on the front of the device.
• Body made of seamless welded sheets.
• Suitable for fruiting small jaws.
• Strong construction with high resistance.
• Shaft made of alloy steel.
• H18 chassis and H12 network coil.
• Using double barrel bearings for rotational rotation.
• Two Ck 45 crank axles with a diameter of 150 mm with gear transmission.
• The bottom sheet of the device is Ck 45 with a thickness of 12 mm and St 37 with a thickness of 15 mm.
• Uniform feeding to primary crushers.
• High flexibility and adaptability with high power.
• Mo 40 plated gear with lubrication tank.
• Connections 70% bolts and nuts and 30% Co2 welding.
• Ability to adjust the vibration range and efficiency of the device.
• Silo 2.5 x 3 meters with 10 stud coils and Co2 welding.
• Complete and advanced lubrication system with the type of lubrication of gears and Vaskazin.
• It has a vibrating mechanism consisting of two shafts.
• Creating the maximum capacity for the next crusher that the feeder is going to feed.
• Bearings and resistant axle with two crank axles to work in tough conditions.
• Low noise performance and maximum vibration due to multiple springs.
• Relatively low price compared to other feeders.
