Technical information:

• The possibility of using it as an initial shredding step depending on the size of the fruit.
• Uniform erosion and as a result stabilization of the amount of crushing of the device.
• High input capability, adjustable throw and high engine power give this crusher the unique ability to handle a wide variety of secondary applications.
• Lower cost of production due to the high power of the engine and the special design of the liners.
• Excellent in secondary applications due to large feed opening.
• Three standard crusher chambers are available for each model.
• The adjustable opening allows fine-tuning of the performance to suit the desired need.
• The power of the electric motor of this device is 220 kW with a pinion shaft speed of 295 horsepower.
• This crusher can be easily adapted to production changes by selecting the crushing chamber: medium coarse crusher, coarse crusher and very coarse crusher.
• High load input capacity compared to the specified size due to the large opening of this crusher.
• Easy maintenance and control of the device and easy replacement of consumable parts.
• Top shell and bottom shell cast with Gs 45 carbon steel.
• Full process control, high efficiency, reduced maintenance costs.
• Main shaft made of Mo 40 alloy steel.
• Concave and mantel made of high quality manganese steel for longer life.
• Suitable for increasing sand production, high output load quality, long life of liners.
• Advanced automatic hydraulic protection system to prevent machine damage.
• Special design and long life of liners.
